Product Description
In addition to narrow linewidth and long coherent length, the frequency stabilized
single frequency laser/narrow linewidth laser has the advantages of stable
frequency and low frequency noise,etc 532nm single longitudinal mode green laser output power and power stability can be choice to free.All solid state single longitudinal mode green
laser at 532nm is made features of ultra compact, long lifetime, low cost and
easy operating, which is used in DNA sequencing, flow cytometry, cell sorting, optical
instrument, spectrum analysis, interference, measurement, holography, physics
experiment, etc.
SPECIFICATIONS:
|
Model
|
MSL-III-532
|
MSL-DS-532
|
MSL-FN-532
|
MSL-F-532
|
MSL-RA-532
|
MSL-R-532
|
Wavelength
(nm)
|
532±2
|
532±1
|
532±1
|
532±1
|
532±1
|
532±1
|
Operating
mode
|
CW
|
Output
power (mW)
|
1-100
|
1-100
|
1-400
|
400-1000
|
1000-2000
|
1-5
|
Power
stability (rms, over 4 hours)
|
<1%,<2%,<3%
|
<1%,<2%,<3%
|
<1%,<2%,<3%
|
<1%,<2%,<3%
|
<1%,<2%,<3%
|
<1%,<2%,<3%.<5%
|
Transverse
mode
|
TEM00
|
Longitudinal
mode
|
Single
|
Spectral
linewidth (nm)
|
<0.00001
|
Coherent
length (m)
|
<50
|
|
Noise
of amplitude (rms, 20Hz~20MHz)
|
<0.5%
|
<0.5%
|
<0.5%
|
<1%,
typical<0.5%
|
<1%
|
<1%
|
M2 factor
|
<1.2(<1.1
optional)
|
<1.2(<1.1
optional)
|
<1.2(<1.1
optional)
|
<1.5
|
<1.2
|
<1.2
|
Beam
diameter at the aperture( 1/e2 ,mm)
|
<1.5
|
0.7±0.05
|
<1.5
|
<2.5
|
<2.0
|
~1.5
|
Beam
divergence, full angle (mrad)
|
<1.2
|
<1.5
|
<1.2
|
<1.2
|
<1.2
|
<1.5
|
Polarization
ratio
|
>100:1
|
|
>100:1
|
|
|
>100:1
|
Pointing
stability after warm-up (mrad)
|
<0.05
|
Warm-up
time (minutes)
|
<10
|
<5
|
<10
|
<10
|
<10
|
<10
|
Beam
height from base plate (mm)
|
24.8
|
19
|
27.4
|
45
|
51
|
58
|
Operating
temperature (℃)
|
10-35
|
0-60
|
15-35
|
15-35
|
10-20
|
10-20
|
Power
supply (90-264VAC)
|
PSU-III-FDA
|
5V
|
PSU-H-FDA
|
PSU-H-FDA
|
PSU-H-FDA
|
PSU-W-FDA
|
|
MSL-III-532
|
PSU-III-FDA
|
|
|
|
MSL-DS-532
|
|
|
MSL-FN-532
|
PSU-H-FDA
|
|
|
|
MSL-F-532
|
PSU-H-FDA
|
|
|
|
MSL-RA-532
|
PSU-H-FDA
|
Water chiller
|
|
|
|
|
MSL-R-532
|
PSU-W-FDA
|
Water Chiller
|
|
|
|
Changchun New Industries Optoelectronics Tech. Co., Ltd. (CNI), founded in 1996, is the leading supplier in China. CNI is dedicated to offer best quality laser,orange laser,high energy laser,raman spectrometer,fluorescence spectrometer and so on.CNI also design and manufacture precision machinery, optical components and optical coating products.
CNI possesses accountable and dependable service as well as quality products with compact design, high reliability, excellent performance. The products are widely used for scientific research,laser for light show,equipment manufacturing, biomedical experiment, precision measurement, entertainment, radar communication, material processing, process control, online detection, investigation equipment and other fields.
